LM- Flexible Batching

>The LEXA-MIX Flexible Batching Vacuum-Mixers are mainly used for cosmetic batch production of semi-solids products 200.000 mpas

>An anchor-type outer agitator with teflon-scrapers to move the product from bottom to the top of vessel. >A propeller-type inner agitator to move the procduct from top to the bottom of vessel. >A bottom mounted homogenizer installed in the center at the bottom of vessel, with a Frequency Inverter to control the required, Product specific share rate. The optimum Share Rate ensures the stability to the emulsion. The Patented increase share edges,reduce batch cycle time-BCT. >The Vacuum-Chamber has a conical bottom and combined with the Homogeniser special transition piece, batch sizes from 10 to 100% are possible. The flexible batching arrangement enables production ' Produce to Demand' and also 'Late Product Differentiation'. >All our Vacuum-Mixers are following the Requirements of cGAP; GAMP; EHEDG; ASME-BPE; NSF-H1; ASME-Section 8; PED; Sustainability; others,

Modular-System: Vacuum-Mixer 50-500ltr with Wax-melter 300ltr and working-platform.

Technical Description

• Triple wall vessel

- with heating- & cooling jacket, conical botom and shell (steam/cooling-water).

- Wetted parts AISI 316L, Surface Ra=0.8micron or better,

• Counter-Rotating Agitator with Frequency Inverter

- The geometrical configuration of the mixing elements are ensuring an superior mixing in the main product-chamber.

- The Teflon scraper takes care of an excellent heat-transfer between inner Vessel Surface and Product.

- The superior mixing and heat-transfer ensures short batch cycle times (BCT)

• Homogenizer with external circulation, with Frequency Inverter

- There are three Options:

1. with Direct Liquid dispersion,(also Hot-Warm-Cold H-W-C),

2. With external circulation, with Direct Liquid and Powder dispersion,

Main Features

° Cost Effective Equipment, with excellent Performance and savings.

° Equipped with Internal CIP-System, driven by

Homogenizer re-circulation.

° Full set of automatic Valves, PLC controlled,

° Full Range of equipment sizes, from 5ltr to 10.000ltr.

° Short batch cycle time (BCT),

° Flexible Batching and Direct Dispersion in Homogeniser,

° 'Produce to Demand (PtD)' and 'Late product Differentiation (LPD)'

Options:

° Hydraulic System to lift Agitator out of Vessel,

° Special Thermometer probe placed at rotating shaft,

° Magnetic Flowmeter in Circulation Pipe,

° Installation and start up service,

° Control System, operation can be Automatic or Semi-Automatic, controlled by PLC and Scada-System (GAMP).

° Modular Systems,
